Precision in paper production
Challenge
Paper manufacturers must produce paper to consistent standards to stay competitive, since uniform paper thickness reduces ink use, saving their customers money. To produce paper, large round rollers turn pulp into sheets of defined thickness. These rollers develop scratches and dents over time, so are periodically reground to give them a good surface finish. Very smooth rollers are required since small variations in roller profile affects paper quality.
Ensuring the regrinding process produces a perfect surface is important, and in-process measurement probes are used to confirm the quality of a roller’s surface as it is repaired. These probes must be periodically sent to calibration labs to ensure they measure correctly, but this risks damage during transit and has the potential to introduce errors after reinstallation on the roller’s spindle.
Reference artefacts that can be installed on the grinding machine would allow the performance of measurement probes to be verified on the machine itself, giving paper manufacturer’s greater confidence that once returned to the production process rollers will produce paper of the required quality.
Solution
The EMRP Project, Traceable in-process dimensional measurement developed a number of well characterised artefacts, with complex shapes and geometries, for use as industrial reference standards. One of these is a reference disc suitable for confirming the measurement accuracy of probes used to assess re-ground paper roller surfaces. Mounted on the roller’s spindle alongside the probe, the disc is used to compare probe results to previous precise measurements of the standard, so verifying the installed probe performance.
The project also investigated factors that contribute to confidence in achieving a true measured value for paper roller surface smoothness, and developed recommendations on how best to determine this. The project derived factors have now been incorporated into written ISO standards to assist with determining measurement uncertainties.
Impact
RollResearch, a Finnish manufacturer of high-tech roll measuring and re-grinding control systems for paper and steel milling, is launching a new calibration service for roller maintenance, as a result of the project.
RollResearch has a four point measuring system that can evaluate wobbles and dimples in rollers as they are being reground, ensuring an optimised surface finish. It uses one of the project reference artefacts, a round disc suitable for in-situ calibration of its measurement instruments. Staff have received training, developed in the project, on determining measurement uncertainties in accordance with the recently updated ISO standards. As a result, Rollresearch can now confidently confirm the ‘roundness’ of rollers as they are being reground, and can now provide customers with a test report for the rollers performance after remedial work has finished.
The new RollResearch calibration service will provide reliable in situ calibration of roll measurement probes to the paper industry. This will improve accuracy and allow corrections to be made during regrinding to reduce roller variations, leading to greater paper uniformity. RollResearch’s customers in the Finnish paper industry, as well as across the EU, Asia and USA, will now have an advanced tool to improve paper quality, helping them to stay ahead of the game in a very competitive market.
